Heat Shield for Orion EFT-1 Spacecraft Arrives at Kennedy for Installation

The heat shield for NASA's Orion EFT-1 spacecraft being unloaded off the agency's Super Guppy heavy transport aircraft at Kennedy Space Center last Wednesday.  Photo Credit: AmericaSpace / Shawn Jakway

The heat shield for NASA’s Orion EFT-1 spacecraft being unloaded off the agency’s Super Guppy heavy transport aircraft at Kennedy Space Center last Wednesday. Photo Credit: AmericaSpace / Shawn Jakway

For nearly 18 months work has continued on NASA’s Orion spacecraft at Kennedy Space Center, where the capsule is currently being constructed for its first flight test next year. The test, known as Exploration Flight Test 1, will put Orion in space on a flight profile which will help validate the spacecraft’s flight control system and heat shield, and last Wednesday the critically important heat shield arrived in style on the agency’s Super Guppy transport.

The one-of-a-kind heat shield, the largest of its kind ever built, will protect the uncrewed Orion spacecraft from succumbing to the intense 4,000-degree inferno of re-entry as it plummets through the Earth’s atmosphere at over 20,000 mph. The Orion capsule itself is still being prepared for its first mission inside Kennedy Space Center’s Operations and Checkout Building, and workers will not actually begin the installation of the heat shield on Orion until next spring (March 2014).

“The heat shield completion and delivery to Kennedy, where Orion is being prepared, is a major step toward Exploration Flight Test-1 next year,” said Dan Dumbacher, NASA’s deputy associate administrator for exploration systems development in Washington. “Sending Orion into space for the first time is going to give us crucial data to improve our design decisions and develop Orion to send humans on future missions to an asteroid and Mars.”

The heat shield for NASA's Orion EFT-1 spacecraft being unloaded at Kennedy Space Center last Thursday.  Photo Credit: AmericaSpace / Jeffrey Soulliere

The heat shield for NASA’s Orion EFT-1 spacecraft being unloaded at Kennedy Space Center last Thursday. Photo Credit: AmericaSpace / Jeffrey Soulliere

Lockheed Martin, the prime contractor for NASA’s Orion Multi-Purpose Crew Vehicle, manufactured the titanium skeleton and carbon-fiber skin that give the heat shield its shape and will provide structural support during landing. The spacecraft was then shipped to Textron Defense Systems near Boston, where the company installed a fiberglass-phenolic honeycomb structure on the heat shield’s carbon-fiber skin before filling each of the honeycomb’s 320,000 cells with Avcoat—a specific ablative heat shield material. Textron then X-rayed and sanded each of the 320,000 cells to match Orion’s design specifications.

The Avcoat will wear away as it heats up during Orion’s violent re-entry into the atmosphere next fall, preventing heat from being transferred to the rest of the capsule and helping the spacecraft to survive its intense fall back to Earth. The heat shield material has already been subjected to arc-jet testing at both NASA’s Ames Research Center in California and NASA’s Johnson Space Center in Houston—both before and during its manufacture. Those tests simulate the heating conditions that a returning Orion will experience, and Orion will face conditions that will bring it through the atmosphere faster than any spacecraft in the last 40 years.

“Many people across the country have poured a tremendous amount of hard work into building this heat shield,” said Orion Program Manager Mark Geyer. “Their efforts are a critical part of helping us understand what it takes to bring a human-rated spacecraft back safely from deep space.”

Map marking milestone events of the EFT-1 mission. Image Credit: NASA

Map marking milestone events of the EFT-1 mission. Image Credit: NASA

Orion’s first flight next year is a crucial step toward development of a crewed version for later in the decade, one which NASA intends to use for deep-space human exploration which leaves low-Earth orbit activities to commercial companies such as SpaceX and Orbital Sciences Corp. Exploration Flight Test-1 will see the unmanned Orion capsule launch atop a mammoth United Launch Alliance Delta-IV Heavy rocket from Cape Canaveral Air Force Station in Florida next fall.

The powerful 24-story-tall launch vehicle will send Orion to orbit the Earth twice while remaining attached to the upper stage of the Delta-IV. After the first orbit, the vehicle will perform a burn to reach an altitude of more than 3,600 miles—fifteen times higher than the orbit of the International Space Station and 10 times higher than any human-rated spacecraft has been since 1972, when the crew of Apollo 17 visited the Moon. Orion will then detach from the Delta-IV upper stage and re-enter the Earth’s atmosphere at more than 20,000 mph—nearly 5,000 mph faster than the space shuttle—before parachuting gently into the Pacific Ocean off the west coast United States.

Technicians work inside the Orion crew module being built at Kennedy Space Center to prepare it for its first power on. Turning the avionics system inside the capsule on for the first time marks a major milestone in Orion’s final year of preparations before its first mission, Exploration Flight Test Photo Credit: Lockheed Martin

Technicians work inside the Orion crew module being built at Kennedy Space Center to prepare it for its first power on. Turning the avionics system inside the capsule on for the first time marks a major milestone in Orion’s final year of preparations before its first mission, Exploration Flight Test.
Photo Credit: Lockheed Martin

Orion is being designed to be reusable for up to 10 flights, capable of carrying four to six astronauts on missions to destinations deeper into space than any human spaceflight mission has ever been. The EFT-1 test flight will be conducted by Lockheed-Martin Space Systems under a NASA contract, serving to check the majority of Orion’s systems and provide teams on Earth with priceless experience and testing that can only be gained from an actual space flight. Test data from the unmanned flight will be used for additional design and development of the capsule, which will ultimately fly a fully operational crewed mission beyond LEO after 2020.

“There are people coast to coast building and developing Orion. Just as this test will check how it all works together in space, it already has pulled that team together on the ground,” adds Geyer. “Their diligence, dedication, and focus have been tremendous, they have truly excelled.”

Artist's illustration of the EFT-1 Orion Multi-Purpose Crew Vehicle (MPVC) on orbit. The mission is expected to take place atop a Delta-IV Heavy rocket in 2014. Image Credit: NASA

Artist’s illustration of the EFT-1 Orion Multi-Purpose Crew Vehicle (MPVC) on orbit. The mission is expected to take place atop a Delta-IV Heavy rocket in 2014. Image Credit: NASA

The spacecraft, at first glance, resembles the Apollo Command and Service Modules—Orion’s CSM and CM are based on those vehicles.  That, however, is where many of the similarities end. Orion is Apollo on steroids: Its rocket launcher (SLS) is bigger and more powerful than Apollo’s Saturn-V, and Orion’s Command Module (CM) is larger than Apollo’s (2.5 times the volume) and can support a larger crew for a longer time. The Service Module (SM) will provide additional space to mount cargo and experiments in addition to providing power and fuel to the spacecraft as well as storing oxygen and water. Orion will benefit from advances derived from the space shuttle program, featuring a “glass cockpit” and a NASA docking system similar to that which was used by the shuttle fleet. Life support, propulsion, thermal protection, and avionics systems will be upgradeable over time as new technologies become available.

After the EFT-1 test flight in 2014, Orion will be put through its first integrated launch in 2017 on the first flight of NASA’s new Space Launch System (SLS) heavy-lift rocket, the launch vehicle chosen to replace the agency’s now retired space shuttle fleet. The mission, Exploration Mission 1 (EM-1), will put the entire integrated system into action, sending Orion more than 40,000 miles beyond the Moon to a deep retrograde orbit where an asteroid could be relocated as early as 2021. Orion will also serve as a backup spacecraft for LEO missions to and from the ISS.

Want to keep up-to-date with all things space? Be sure to “Like” AmericaSpace on Facebook and follow us on Twitter: @AmericaSpace


BELOW:
 Photos from Orion’s heat shield arrival aboard NASA’s Super Guppy cargo transport at Kennedy Space Center last Thursday. All images are © copyright to their respective photographers, all rights reserved.

Photo Credit: AmericaSpace / Jeffrey Soulliere

Photo Credit: AmericaSpace / Jeffrey Soulliere

Photo Credit: AmericaSpace / Matt Gaetjens

Photo Credit: AmericaSpace / Matt Gaetjens

Photo Credit: AmericaSpace / Jeffrey Soulliere

Photo Credit: AmericaSpace / Jeffrey Soulliere

Photo Credit: AmericaSpace / Shawn Jakway

Photo Credit: AmericaSpace / Shawn Jakway

Photo Credit: AmericaSpace / Matt Gaetjens

Photo Credit: AmericaSpace / Matt Gaetjens

IMG_9528

Photo Credit: AmericaSpace / Shawn Jakway
