Atlantis rockets into the night on 28 February 1990, headed for the shuttle's first "dogleg" maneuver and the highest orbital inclination ever attained by a U.S. piloted spacecraft. Photo Credit: NASA, via Joachim Becker/SpaceFacts.de

Atlantis rockets into the night on 28 February 1990, headed for the shuttle’s first “dogleg” maneuver and the highest orbital inclination ever attained by a U.S. piloted spacecraft. Photo Credit: NASA, via Joachim Becker/SpaceFacts.de

A quarter-century has now passed since one of the quietest missions in the shuttle’s 30-year operational history. On 28 February 1990, the orbiter Atlantis and her STS-36 crew—Commander John “J.O.” Creighton, Pilot John Casper, and Mission Specialists Mike Mullane, Dave Hilmers, and Pierre Thuot—rocketed into orbit for four days of activities on behalf of the Department of Defense. During that short period of time, the astronauts deployed a classified payload, known at the time as Air Force Program (AFP)-731, but more commonly known under the program name of “Misty,” whose nature even today continues to mystify. As described in yesterday’s AmericaSpace history article, Atlantis performed a “dogleg” maneuver during ascent to reach the highest inclination (62 degrees) ever achieved by a U.S. human space mission.

Having said that, Atlantis’ altitude on STS-36 was one of the shuttle’s lowest, often reaching only a little higher than 125 miles (200 km). For Mullane, this presented stunning views of Earth, which made the Home Planet seem “hugely close.” The wind-rippled waves of the oceans were visible in astonishing clarity and, flying over the Caribbean Sea, the humps and valleys of the sea floor stood out in stark relief. Elsewhere, supertankers in the Persian Gulf could be seen, with their V-shaped wakes glinting in the sunlight, whilst further south, ribbons of plankton stretched out to sea on the fringes of Antarctica. On one occasion, Mullane saw a flotilla of icebergs in the Southern Ocean and used gyroscopically stabilized binoculars to take a look at the distant land mass of Antarctica. “The pole was nearly 1,800 miles (2,900 km) distant,” he wrote in Riding Rockets, “so I had no view of it. Instead, I focused on the rugged coastal mountain chains. The occasional black of a windswept cliff was the only color in an otherwise sheet-white topography.”

Floating horizontally, he found that he could roll himself into a ball and plant his face against Atlantis’ forward flight deck windows, which, with the cockpit lights switched off, made it seem as if he were snorkeling in the Aegean Sea, watching the iridescence of sea life through a face mask. Over the Pacific Ocean, as trade winds of the northern and southern hemispheres met and mixed in the heat and humidity of the equator, ominous clouds flickered with electricity—“sputtering fluorescent light bulbs,” Mullane called them—as thunderstorms rippled across the region. He had already decided that STS-36 would be his final mission and was determined to spend this quiet time at the windows on his last full evening in space. Every hour and a half, Atlantis brushed the Arctic and Antarctic Circles and the astonishing diversity of Earth was displayed, map-like, beneath him: the dense Siberian taiga, the rolling dunes of the African deserts, punctuated in their north-eastern corner by the green of the Nile Delta, the snow-capped mountaintops of the Himalaya and the Andes … and, finally, the place he called home: the sprawling city of Albuquerque, N.M. Bordered by the Sandia Mountains to the east and with the mighty Rio Grande flowing through it, from north to south, this was the place to which Mullane and his wife intended to return.

Pictured in the flight deck simulator, the STS-36 crew consisted of (from left) John Casper, Pierre Thuot, Dave Hilmers, Mike Mullane and John "J.O." Creighton. Photo Credit: NASA, via Joachim Becker/SpaceFacts.de

Pictured in the flight deck simulator, the STS-36 crew consisted of (from left) John Casper, Pierre Thuot, Dave Hilmers, Mike Mullane, and John “J.O.” Creighton. Photo Credit: NASA, via Joachim Becker/SpaceFacts.de

More than two decades later, Atlantis’ flight remains secret, although it is known that AFP-731 was deployed on the second day in orbit. “The payload had been expected to be deployed at 27 hours into the mission,” wrote observer Ted Molczan, based in the Canadian capital, Toronto. However, observations made some 28-31 hours into the mission revealed only the orbiter and, somewhere between 34-35 hours, Atlantis’ orbit changed slightly, providing clear evidence of a separation maneuver from the payload. “Therefore, deployment probably occurred between 31.5 and 35.3 hours,” concluded Molczan. “It is possible that it occurred earlier and that the spacecraft were too close together to separate it with binoculars.” Certainly, the “separation burn” took place on the afternoon of 1 March and the payload was sighted, in an orbit of 154 x 161 miles (248 x 260 km), some 57 seconds in time “behind” Atlantis, on the morning of the 2nd.

Creighton and his crew returned to Earth on 4 March 1990, touching down at Edwards Air Force Base, Calif., at 10:08 a.m. PST. Sketchy details trickled out in the following weeks: that AFP-731 was some sort of electro-optical reconnaissance platform, possibly with a signals intelligence component, and that it utilized a mechanism known as the Stabilized Payload Deployment System (SPDS), which “rolled” it over the shuttle’s payload bay wall and released it in an offset, near-vertical angle of between 65-80 degrees. The SPDS, described in a 1989 paper by Johnson Space Center (JSC) engineers Guy King and Ted Tsai, was an electromechanical structure, capable of rotating the payload longitudinally out of the bay at a pre-determined angular position and separating it on command. Mounted on the port side of the bay, it took the position normally occupied by the Canadian-built Remote Manipulator System (RMS) mechanical arm.

“Two separable hinge-like devices connect at one longitudinal side or edge of the payload to respective ones of the payload trunnions at different longitudinally-spaced locations along the length of the payload,” the NASA Patent Application for SPDS revealed. “Separation of the payload from the bay is made [by] unlatching a latch and by the use of a repulsion spring at the position of each hinge-like device. Two four-link mechanisms allow movement between payload and bay. Such accommodative movement is required, especially duting launch, when considerable vibration is encountered.” One of the key aims of the SPDS was to more safely maneuver a payload away from the shuttle. “It is a feature of the present invention that the payload is safely outside of the bay before it is separated from the shuttle,” the patent application continued. “This makes it possible … to prevent the payload from colliding with the shuttle. The separation … is thus less hazardous.” Having said this, redundancy was provided in the form of a pyrotechnic separation system.

The official crew patch for shuttle mission STS-36, which launched 25 years ago today, on 28 February 1990. Image Credit: NASA

The official crew patch for shuttle mission STS-36, which launched 25 years ago today, on 28 February 1990. Image Credit: NASA

“After the payload is stabilized,” wrote King and Tsai in their paper, “it is released through a double swivel toggle release mechanism, located within the release head.” By the time Atlantis landed, observers had already noticed that the satellite had increased its altitude from 158 miles (254 km) to 168 miles (271 km), and on 7 March 1990 it executed a much larger maneuver. After the sighting of the five mysterious objects in late March, nothing more was seen until mid-October 1990, when a team of European observers tracked something at an altitude of 504 miles (811 km), inclined 65 degrees to the equator.

Although the United Nations had received no notification of anything operating in that region, analysis of AFP-731’s track suggested that it was the closest possible contender, and it was suggested that the “debris” seen in March was actually associated with the transfer of the satellite to its operational orbit. Certainly, this orbit was adjusted again in early November—possibly to monitor the deteriorating situation in the Persian Gulf; Saddam Hussein having invaded Kuwait the previous August—although attempts to “find” it in the weeks which followed were unsuccessful. It has also been suggested that another of AFP-731’s targets were the Soviet Union’s military assets in the Arctic Ocean, particularly the strategic archipelago of Novaya Zemlya.

Over the years, the satellite’s “vanishing trick” was assumed to represent an example of a new-generational spacecraft, capable of demonstrating optical or radar stealth to prevent adversaries from monitoring it or predicting exactly when it would overfly their territories. Not until 1996-97 was AFP-731 seen again by civilian observers, purely by chance, in binoculars, at an inclination of 66.2 degrees and a lower altitude of about 457 miles (736 km), and more recent speculation has been aired that it possessed some form of inflatable “shield,” perhaps conical in shape and composed of very thin polymers, coated with highly reflective gold or aluminum. This shield, it is theorized, was designed to suppress the satellite’s optical or radar signature.

Today, it is often known by the code name of “Misty” and is thought to have been built by Lockheed Martin, specifically as a “low-observable” spacecraft at a unit cost of around $360 million. Its original purpose, according to GlobalSecurity.org, was to permit the United States to catch the Soviets cheating on arms control agreements. A second Misty satellite is believed to have been inserted into orbit in May 1999, and there has been some suspicion that the National Reconnaissance Office’s NROL-15 mission—launched in June 2012—may have been a follow-on member of the same or similar class. However, it is generally assumed that STS-36’s first-generation Misty was probably deorbited sometime after 1997.

After four days in space, Atlantis touches down at Edwards Air Force Base, Calif., on 4 March 1990. Photo Credit: NASA

After four days in space, Atlantis touches down at Edwards Air Force Base, Calif., on 4 March 1990. Photo Credit: NASA

Whilst the two Defense Satellite Communications System (DSCS) military communications satellites deployed by the shuttle on Mission 51J in October 1985 were unveiled a little more than a decade after launch, it seems highly unlikely that any concrete facts will be revealed about intelligence platforms like Misty for many years to come. The STS-36 crew had all been subjected to intensive background checks by the intelligence community during the astronaut application process, but flying on a Department of Defense mission required a new level of security clearance. “There was additional background information,” Creighton remembered, “because you were going to be cleared Top Secret for a clearance. Most of the military guys had already had a Top Secret clearance when they were in the military, but it’s only good for specific purposes. I’m sure they did a background check on us before we were announced as a crew, unbeknownst to any of us.”

Creighton’s recollection is that only about two dozen other souls knew exactly what happened for the entirety of STS-36, including NASA Administrator Dick Truly and the mission’s flight directors. “Most of the people in Mission Control didn’t know specifically what we did,” he added. Yet for five military officers—Creighton and Thuot were both Navy, Casper and Mullane were Air Force, and Hilmers was a Marine—the sense of pride at completing a mission for the national security interest was pervasive. “Even though I can’t talk about them,” Mike Mullane said, “I feel very, very proud about those DoD missions. I felt like that was something that had a significant impact on America’s security … and I was part of it.”
