‘Really a Smoothie’: Remembering Gemini VIII, OTD in 1966 (Part 1)

Neil Armstrong (left) and Dave Scott sought to fulfil many of the objectives needed to reach the Moon, including orbital rendezvous and docking. They were the only Gemini crew whose two members both walked on the Moon in their later careers. Photo Credit: NASA

At the dawn of 1966, America’s drive to land a man on the Moon had accelerated into high gear. Five Gemini crews had shown that astronauts could survive in space for long enough to complete the journey and that it was possible to venture outside in a pressurized suit and perfect the tricky technique of orbital rendezvous. All would someday be critical in enabling the first steps on another world. On Gemini VIII in March 1966, astronauts Neil Armstrong and Dave Scott sought to press the envelope still further.

Video Credit: NASA

They would spend three days in space, perform rendezvous and, for the first time, physical docking with another object, and execute combined maneuvers, scientific experiments, a two-hour Extravehicular Activity (EVA), and a precision re-entry and splashdown. In time, Armstrong and Scott would both leave their bootprints on the lunar surface—the only Gemini crew to do so—but their ill-fated flight together, 55 years ago, brought them within a whisker of losing their lives.

The pair had been together since the end of August 1965 and neither man was under any illusion about the complexity of their task. The EVA was particularly crucial. Unlike America’s first spacewalker, Ed White, who had moved around for barely a few minutes, Scott would maneuver to the rear of Gemini VIII, reverse himself into a backpack known as the Extravehicular Support Package (ESP) and attach a tether.

Pictured in July 1965, Neil Armstrong sits in the simulator during training as backup command pilot for Gemini V. Photo Credit: NASA

This would allow him to venture up to 90 feet (27 meters) from the spacecraft. He would spacewalk through orbital daytime and nighttime, retrieve an emulsion package, activate a micrometeoroid collector on the Agena target spacecraft, and test a reactionless power wrench.

It was only the second time an American had left his craft in space and Scott’s work was laden with risk; if he hit difficulties, there would be no way for Armstrong to see or reach him. Aware of this risk, Armstrong had requested realistic training models of the Gemini’s aft adaptor section and a series of rehearsals in an altitude chamber. By the eve of launch, Scott had practiced his movements on 200 parabolic aircraft flights and more than 20 hours on an air-bearing table.

Dave Scott was tasked with performing a two-hour spacewalk during Gemini VIII. Photo Credit: NASA

Scott knew that to operate effectively within a space suit he needed to maintain his physical fitness and strength with his exercise routine and using supplements like this CBD tinctures. This was particularly true from conversations with Ed White, who had experienced difficulty closing the Gemini’s hatch at the end of his own EVA. A lever had been fitted to make it a bit easier, but White cautioned Scott that the suit was stiff and heavy and demanded enormous reserves of stamina for any movement, let alone two hours of physical work. Scott jogged, played handball, and pumped iron in the gym, which brought him face to face with Neil Armstrong’s wry humor.

When it came to physical exertion, Armstrong had one cardinal rule: Human beings had a finite number of heartbeats and should not waste them with frivolity! One day, during Gemini VIII training, as a sweat-drenched Scott worked out, Armstrong set the exercise bicycle on its lowest possible setting and began pedaling.

The Gemini VIII prime and backup crews (from left) Dave Scott, Neil Armstrong, Charles “Pete” Conrad and Dick Gordon take journalists’ questions at a pre-launch press conference. Photo Credit: NASA

The training uncovered obstacles that might have threatened Scott’s life. The air-bearing table, for example, allowed him to literally “fly” across a surface and demonstrate a hand-held maneuvering gun. The gun was filled with Freon, a relatively dense refrigerant, and the strength of its impulse caused Scott to worry about how it might perform in space. In one test at low temperatures, the Freon caused the gun’s poppet valve to stick “open” when triggered. Had this occurred in the frigid cold of orbital flight, the escaping gas might have caused Scott to tumble uncontrollably.

Elsewhere, there were concerns that an injector in the space suit’s chest pack might freeze and prevent the flow of oxygen, and trials inside the cramped Gemini cabin left some engineers literally “tangling” with the problem of a jumble of floating umbilicals, tethers, and jumper cables. Not until December 1965 did Scott feel confident that he could complete the task.

Armstrong and Scott depart for the launch pad on 16 March 1966. Photo Credit: NASA

On the morning of 16 March 1966, the two astronauts awoke in their crew quarters at Cape Kennedy and breakfasted on filet mignon, eggs, and toast with butter and jelly. The skies above Cape Kennedy were clear, blue and cloud-speckled and conditions seemed perfect for the launch of their Agena-D target vehicle—a pencil-shaped craft, mounted atop an Atlas rocket—at 10 a.m. EST and their own launch at 11:40 a.m.

As they donned their suits, a watch belonging to aviation pioneer Jimmy Mattern was strapped around Armstrong’s wrist and pieces of wood and cloth from an old Douglas World Cruiser, the New Orleans, were packed with Scott’s personal effects. Both were on loan from the museum at Wright-Patterson Air Force Base, near Dayton, Ohio. At Pad 19, where the spacecraft sat atop its Titan II booster, a glitch with Scott’s parachute harness required Gemini VIII backup command pilot Charles “Pete” Conrad to ferret around for a toothpick to remove epoxy resin from the catcher mechanism.

The prime crew boards the elevator at Pad 19. Photo Credit: NASA

As the clock struck 10, the Atlas-Agena combination thundered away from Pad 14, inserting the vehicle perfectly into orbit. By now alone in the cramped cabin of Gemini VIII, the astronauts were elated. The first stage of their mission was running smoothly. “Cradled in my contoured seat,” Dave Scott wrote in his autobiography, Two Sides of the Moon, “it felt almost as if I was being held in someone’s arms.” The Gemini felt as snug and crisp as a brand-new Ferrari, and the pure oxygen atmosphere provided a cool sense of freshness and cleanness to the cabin.

Under the direction of Flight Director John Hodge, Gemini VIII itself rose from the pad at 11:41 a.m. The astronauts felt  “a solid feeling, a sharp kick in the tail” as the Titan delivered them smoothly into space. Scott’s heart rate peaked at 128 beats per minute, with Armstrong’s reaching 146; post-mission analysis would determine that the difference was attributable to a “keying-up” of the command pilot’s physical and psychological awareness, rather than an indicator of undue stress.

Gemini VIII’s target, the Agena vehicle, is launched from Cape Kennedy atop an Atlas rocket on 16 March 1966. Photo Credit: NASA

Armstrong told his biographer, James Hansen, that the ascent was “very definite” and that although the Titan’s thrust was noticeable, it did not interfere with communications. By the time the first stage separated and the second stage ignited, Scott described the ride as “smooth as glass” and, minutes later, was amused to let go of his checklist and watch it drift across the cabin.

Nothing could have prepared either man for his first glimpse of Earth. As Armstrong rolled Gemini VIII they beheld the deep trench of the Mediterranean Sea, with Italy clearly visible, and far on the horizon the unmistakable shapes of the Middle East and the Red Sea.

Gemini VIII was launched on 16 March 1966, atop a Titan II booster, from Pad 19 at Cape Kennedy. Photo Credit: NASA

In those euphoric seconds, Scott realized that his camera would do no justice to this scene; privately he hoped that NASA would someday send an artist or a poet into orbit to describe it better. Nonetheless, he broke out his camera and starting shooting. Armstrong, too, was overwhelmed. He had flown the X-15 rocket aircraft to an altitude of more than 40 miles (64 km) and had seen the curvature of the Home Planet, but this was four times higher and something quite different.

Armstrong and Scott were trailing the Agena by a little over 1,000 miles (1,600 km) and were scheduled to rendezvous and dock with it later that same day, before performing the EVA. Ninety minutes into the mission, they fired Gemini VIII’s thrusters to slightly lower their orbital apogee. A second burn raised their perigee and a third, at 2:27 p.m., placed them into roughly the same orbital plane as the Agena.

From a distance of 260 feet (79 meters), the Agena-D target vehicle comes clearly into view. Photo Credit: NASA

“A fundamental requirement of rendezvous,” Armstrong told Hansen, “is to get your orbit into the same plane as the target’s orbit, because if you’re misaligned by even a few degrees, your spacecraft won’t have enough fuel to get to its rendezvous target.” By launching in a tightly defined time span and entering orbit within a few tenths of a degree of the target, Gemini VIII was thus poised.

Betwixt the thrusters burns, Armstrong and Scott broke for lunch. Indeed, “broke” was an apt choice of word. The chicken and gravy casserole, despite having been rehydrated, was quite dry, and the men’s chocolate brownie cookies stuck together and crumbled. Fortunately, they were running on reserves of adrenaline and eating was the last thing on their mind.

Gemini VIII approaches the Agena-D target vehicle, a few hours after liftoff on 16 March 1966. Photo Credit: NASA

At length, the Agena was detected by radar at a distance of about 200 miles (320 km), and another burn of Gemini VIII’s thrusters, high above Madagascar, aligned them with perfection for the “terminal” phase of the rendezvous. An hour later, at 4:21 p.m., Scott visually sighted the target, less than 80 miles (130 km) away, its rendezvous beacon blinking against the black sky.

Drifting into orbital nighttime, they lost sight of it, although its beacon was still apparent, and when they re-established visual contact Armstrong prepared for docking. He was now braking Gemini VIII by eyesight alone, firing off short spurts of the thrusters and, at length, the men’s craft came into position, close to the Agena, with no relative velocity. Thirty minutes later, after checking that the target was undamaged, they prepared to move in for docking.

Video Credit: Smithsonian Channel

The complexity and importance of this maneuver cannot be underestimated. No previous physical docking had ever been accomplished by a manned craft, and, with NASA planning Lunar Orbital Rendezvous (LOR) as part of its scheme to land on the Moon, the work of Armstrong and Scott was absolutely critical. As the command pilot guided his ship gingerly closer, he experienced no problems; in fact, fellow astronaut Wally Schirra—who performed a rendezvous between Gemini VI-A and Gemini VII the previous December—had assured him that flying close to another vehicle was very easy when the correct positioning had been achieved.

For 25 minutes, Armstrong and Scott electronically checked the Agena’s systems, antennas and lights by radio command and by now were so close that they could read a small instrument panel above its docking collar. At 6:15 p.m., less than seven hours after launch, Armstrong became the first human being to dock with another craft in orbit. An electronic motor aboard the Agena retracted the collar, pulled the Gemini’s nose into the target, and connected their electrical systems. The instrument panel on the Agena displayed a green “rigid” confirmation.

Gemini VIII’s nose edges into the docking collar of the Agena target. Although this mission achieved a successful rendezvous and docking, it fell victim to violent oscillations, due to a stuck-on thruster, which almost cost Neil Armstrong and Dave Scott their lives. Photo Credit: NASA

Both vehicles were electrically and mechanically mated. They had done it.

“Flight, we are docked,” Armstrong announced, with more than a hint of triumph, “and it’s really a smoothie!” There was no noticeable oscillations, he reported, in the combined craft. In the Mission Operations Control Room (MOCR) at the Manned Spacecraft Center (MSC) in Houston, Texas, sheer pandemonium broke out. The achievement of Gemini VIII had cleared another hurdle on the road to the Moon.

Armstrong’s “smoothie,” though, would be the last time that anyone on the ground or in orbit would breathe easily. Within minutes, Gemini VIII would change from a perfect flight into a very real battle for survival.

The second part of this article will appear tomorrow.
