New Horizons Finishes Returning Pluto Data to Earth Before Continuing Farther into Kuiper Belt

Artist's depiction of data being sent by New Horizons back to Earth. Image Credit: NASA/JHUAPL/SwRI
Artist’s depiction of data being sent by New Horizons back to Earth. Image Credit: NASA/JHUAPL/SwRI

To say that the New Horizons mission has been a success would be a massive understatement; this first-ever spacecraft to visit Pluto has revolutionized our understanding of this distant, small world. Pluto and its moons are complex and active places, more so than thought possible by most scientists. Even though New Horizons flew past Pluto instead of orbiting it in July 2015, it still collected an enormous amount of information, which has taken more than a year to be sent back to Earth. That process is now complete, NASA just announced.

Over 50GB of data was sent back to Earth in total, with the last bits being downlinked at 5:48 a.m. EDT on Oct. 25, at the Johns Hopkins Applied Physics Laboratory (JHUAPL) in Laurel, Md. The data had to travel over 3.4 billion miles (5.5 billion kilometers), or five hours and eight minutes at the speed of light, to reach Earth from New Horizons, which is now well beyond Pluto.

“The Pluto system data that New Horizons collected has amazed us over and over again with the beauty and complexity of Pluto and its system of moons,” said Alan Stern, New Horizons principal investigator from Southwest Research Institute in Boulder, Colo. “There’s a great deal of work ahead for us to understand the 400-plus scientific observations that have all been sent to Earth. And that’s exactly what we’re going to do – after all, who knows when the next data from a spacecraft visiting Pluto will be sent?”

“We’re excited about the exploration ahead for New Horizons, and also about what we are still discovering from Pluto flyby data,” Stern also said. “Now, with our spacecraft transmitting the last of its data from last summer’s flight through the Pluto system, we know that the next great exploration of Pluto will require another mission to be sent there.”

High-resolution view of Pluto from New Horizons. The large smoother area of ice in Sputnik Planum is the western lobe of the “heart” feature. Image Credit: NASA/JHUAPL/SwRI
High-resolution view of Pluto from New Horizons. The large smoother area of ice in Sputnik Planum is the western lobe of the “heart” feature. Image Credit: NASA/JHUAPL/SwRI
Images of possible clouds on Pluto, as seen by New Horizons.
Images of possible clouds on Pluto, as seen by New Horizons. The other bright layers are haze in the thin atmosphere. Image Credit: NASA/JHUAPL/SwRI

Since the mission was only a quick flyby of Pluto, New Horizons had to gather as much data as it could as fast as it could; there were no second chances. During closest approach, the spacecraft gathered about 100 times more data than it could have sent back before continuing its journey past Pluto, deeper into the Kuiper Belt. Fortunately, everything worked beautifully.

“We have our pot of gold,” said Alice Bowman, Mission Operations Manager at JHUAPL.

The mission team will now erase the two onboard data recorders to make room for new data, but not before conducting a final data-verification review.

Before New Horizons, the best views we had of Pluto were from the Hubble Space Telescope, and even then it wasn’t much more than a small fuzzy blob. Now, the surfaces of Pluto and its moons have been seen in incredible detail, revealing worlds much more active than ever previously thought.

Pluto itself, it turned out, had vast glaciers and plains of smooth nitrogen ice, tall mountain ranges of solid water ice with methane snow on their peaks, ancient riverbeds which once flowed with liquid nitrogen, a bluish hazy layered atmosphere with possible clouds, possible current cryovolcanoes (ice volcanoes), and a possible current subsurface ocean of water. Its largest moon, Charon, had deep tectonic fissures and valleys, mountains (including an odd isolated peak sitting in a moat-like shallow depression), landslides, and a distinct reddish north polar cap.

The “blue skies of Pluto” as seen by New Horizons after closest approach, one of the most iconic images of the mission. Soot-like particles in the atmosphere scatter sunlight in a way that the atmosphere appears blue. This backlit view of Pluto can never be seen from Earth. Image Credit: NASA/JHUAPL/SwRI
The “blue skies of Pluto” as seen by New Horizons after closest approach, one of the most iconic images of the mission. Soot-like particles in the atmosphere scatter sunlight in a way that the atmosphere appears blue. This backlit view of Pluto can never be seen from Earth. Photo Credit: NASA/JHUAPL/SwRI

The fact that Pluto and its moons have been and still are so geologically active was a surprise to scientists, since they are all so small and so far from the Sun in the deep outer reaches of the Solar System. But active they were.

The following is a summary of some of the key findings so far, from five papers published last spring:

  • The age-dating of Pluto’s surface through crater counts has revealed that Pluto has been geologically active throughout the past 4 billion years. Further, the surface of Pluto’s informally-named Sputnik Planum, a massive ice plain larger than Texas, is devoid of any detectable craters and estimated to be geologically young—no more than 10 million years old.\
  • Pluto’s moon Charon has been discovered to have an ancient surface. As an example, the great equatorial expanse of smooth plains on Charon informally named Vulcan Planum (home of the “moated mountains” informally named Kubrick and Clarke Mons) is likely a vast cryovolcanic flow or flows that erupted onto Charon’s surface about 4 billion years ago. These flows are likely related to the freezing of an internal ocean that globally ruptured Charon’s crust.
  • The distribution of compositional units on Pluto’s surface – from nitrogen-rich, to methane-rich, to water-rich – has been found to be surprisingly complex, creating puzzles for understanding Pluto’s climate and geologic history. The variations in surface composition on Pluto are unprecedented elsewhere in the outer solar system.
  • Pluto’s upper atmospheric temperature has been found to be much colder (by about 70 degrees Fahrenheit) than had been thought from Earth-based studies, with important implications for its atmospheric escape rate. Why the atmosphere is colder is a mystery.
  • Composition profiles for numerous important species in Pluto’s atmosphere (including molecular nitrogen, methane, acetylene, ethylene, and ethane) have been measured as a function of altitude for the first time.
  • Also for the first time, a plausible mechanism for forming Pluto’s atmospheric haze layers has been found. This mechanism involves the concentration of haze particles by atmospheric buoyancy waves (called “gravity waves” by atmospheric scientists), created by winds blowing over Pluto’s mountainous topography.
  • Before the flyby, the presence of Pluto’s four small moons raised concerns about debris hazards in the system. But the Venetia Burney Student Dust Counter only counted a single dust particle within five days of the flyby. This is similar to the density of dust particles in free space in the outer solar system – about 6 particles per cubic mile – showing that the region around Pluto is, in fact, not filled with debris.
  • New Horizons’ charged-particle instruments revealed that the interaction region between the solar wind and Pluto’s atmosphere is confined on the dayside of Pluto to within 6 Pluto radii, about 4,500 miles (7,000 kilometers). This is much smaller than expected before the flyby, and is likely due to the reduced atmospheric escape rate found from modeling of ultraviolet atmospheric occultation data.
  • The high albedos (reflectiveness) of Pluto’s small satellites – about 50 to 80 percent – are entirely different from the much lower albedos of the small bodies in the general Kuiper Belt population, which range from about 5 to 20 percent. This difference lends further support to the idea that these satellites were not captured from the general Kuiper Belt population, but instead formed by agglomeration in a disk of material produced in the aftermath of the giant collision that created the entire Pluto satellite system.
Closer view of the rugged mountainous highlands adjacent to the edge of Sputnik Planum. Photo Credit: NASA/JHUAPL/SwRI
Closer view of the rugged mountainous highlands of water ice adjacent to the edge of the Sputnik Planum plains and glaciers of nitrogen ice. Photo Credit: NASA/JHUAPL/SwRI
View of what is thought to be a frozen lake on Pluto, composed of nitrogen ice. Pluto also used to have rivers of liquid nitrogen. Photo Credit: NASA/Johns Hopkins University Applied Physics Laboratory/Southwest Research Institute
View of what is thought to be a frozen lake on Pluto, composed of nitrogen ice. Pluto also used to have rivers of liquid nitrogen. Photo Credit: NASA/JHUAPL/SwRI

“These five detailed papers completely transform our view of Pluto – revealing the former ‘astronomer’s planet’ to be a real world with diverse and active geology, exotic surface chemistry, a complex atmosphere, puzzling interaction with the Sun and an intriguing system of small moons,” said Stern.

The evidence for a possible subsurface ocean on Pluto is intriguing, and would put the dwarf planet in company with several moons which also have subsurface oceans, such as Europa, Enceladus, Titan, Ganymede, and possibly others.

“Thanks to the incredible data returned by New Horizons, we were able to observe tectonic features on Pluto’s surface, update our thermal evolution model with new data and infer that Pluto most likely has a subsurface ocean today,” said Noah Hammond, a graduate student in Brown University’s Department of Earth, Environmental and Planetary Sciences.

It had been theorized that if Pluto did once have a subsurface ocean, it would be completely frozen by now, but the data from New Horizons seemed to suggest otherwise.

“We don’t see the things on the surface we’d expect if there had been a global contraction,” Hammond said. “So we conclude that ice II has not formed, and therefore that the ocean hasn’t completely frozen.”

Pluto’s largest moon Charon has an unusual reddish-colored north polar cap, and scientists think it results from methane escaping Pluto’s atmosphere and condensing on Charon’s cold surface. Sunlight then converts the methane ice into reddish tholins. Photo Credit: NASA/Johns Hopkins University Applied Physics Laboratory/Southwest Research Institute
Pluto’s largest moon Charon has an unusual reddish-colored north polar cap, and scientists think it results from methane escaping Pluto’s atmosphere and condensing on Charon’s cold surface. Sunlight then converts the methane ice into reddish tholins. Photo Credit: NASA/JHUAPL/SwRI

There is also evidence that Pluto’s largest moon Charon had a subsurface ocean as well, but it is likely completely frozen solid.

Pluto’s thin atmosphere appears bluish when seen backlit by the Sun, a view never possible from Earth. There is also evidence for possible clouds in that hazy, layered atmosphere.

They appear to be relatively few and far between as compared to clouds on Earth, but as Stern noted, “If there are clouds, it would mean the weather on Pluto is even more complex than we imagined.”

Most recently, it was found that Pluto emits x-rays and “paints” Charon with methane gas, which explains the reddish polar cap on that moon. The methane freezes at Charon’s north pole and then ultraviolet light from the Sun changes the material into heavier hydrocarbons and eventually into reddish organic materials called tholins.

“Who would have thought that Pluto is a graffiti artist, spray-painting its companion with a reddish stain that covers an area the size of New Mexico?” asked Will Grundy, a New Horizons co-investigator from Lowell Observatory in Flagstaff, Ariz., and lead author of the new paper. “Every time we explore, we find surprises. Nature is amazingly inventive in using the basic laws of physics and chemistry to create spectacular landscapes.”

As for the x-rays, they are produced by Pluto interacting with the solar wind from the Sun. They were first found by NASA’s Chandra X-ray Observatory.

One of the instruments on New Horizons, the Solar Wind Around Pluto (SWAP), measured the “bowshock,” where the solar wind first “meets” Pluto and its atmosphere (similar to a shock wave that forms ahead of a supersonic aircraft) and forms a small wake or tail behind the dwarf planet. When the data from Chandra was first examined, however, it showed that the brightness of the x-rays around Pluto was much higher than expected. It isn’t clear yet why there is a difference between the New Horizons and Chandra findings, but for scientists that is just an opportunity to learn more.

“We’ve just detected, for the first time, X-rays coming from an object in our Kuiper Belt, and learned that Pluto is interacting with the solar wind in an unexpected and energetic fashion,” said Carey Lisse, an astrophysicist at JHUAPL, who led the Chandra observation team with APL colleague and New Horizons Co-Investigator Ralph McNutt. “We can expect other large Kuiper Belt objects to be doing the same.”

So what is next for New Horizons? The spacecraft is continuing its journey deeper into the Kuiper Belt region of the outer Solar System. A new mission extension, called “KEM,” or Kuiper Belt Extended Mission, will allow the probe to investigate other objects in the Kuiper Belt. The next close flyby will be of a Kuiper Belt Object (KBO) called 2014 MU69, on Jan. 1, 2019. This flyby has been discussed before on AmericaSpace, but now would be part of a larger extended mission plan. 2014 MU69 is much smaller than Pluto, only about 13 to 25 miles (21 to 40 kilometers) across (similar in size to Mars’ two tiny moons), but New Horizons would fly past at a distance of only about 1,900 miles (3,000 kilometers), four times closer than the Pluto flyby.

Observations by the Hubble Space Telescope have shown that 2014 MU69 is red in color, maybe even redder than Pluto.

“The reddish color tells us the type of Kuiper Belt object 2014 MU69 is,” said Amanda Zangari, a New Horizons post-doctoral researcher from Southwest Research Institute. “The data confirms that on New Year’s Day 2019, New Horizons will be looking at one of the ancient building blocks of the planets.”

After Pluto, New Horizons will continue its journey deeper into the Kuiper Belt. Image Credit: NASA/Johns Hopkins University Applied Physics Laboratory/Southwest Research Institute
After Pluto, New Horizons will continue its journey deeper into the Kuiper Belt. Image Credit: NASA/JHUAPL/SwRI

It will be interesting to see this KBO up close and find out how similar to, or different from, other bodies such as Pluto and Charon it is.

The primary objectives of the 2014 MU69 flyby include:

  • Make distant flyby observations of about 20 other KBOs during 2016-2020, determining their shapes, satellite populations, and surface properties—something no other mission or ground-based telescope can.
  • Make sensitive searches for rings around a wide variety of KBOs during 2016-2020.
  • Conduct a heliospheric transect of the Kuiper Belt, making nearly continuous plasma, dust, and neutral gas observations from 2016 to 2021, when the spacecraft reaches 50 astronomical units (AU) from the Sun.
  • Potentially conduct astrophysical cruise science in 2020 and 2021, after the MU69 flyby, if NASA desires.

New Horizons also recently obtained images of another KBO called 1994 JR1. It is only one of thousands of such objects, but by studying it scientists can learn more about KBOs in general, including larger ones such as Pluto.

As noted by Stern: “The Kuiper Belt is a rich scientific frontier. Its exploration has important implications for better understanding comets, the origin of small planets, the Solar System as a whole, the solar nebula, and dusty Kuiper Belt-like disks around other stars, as well as for studying primitive material from our own Solar System’s planet formation era. The exploration of the Kuiper Belt and KBOs like MU69 by New Horizons would transform Kuiper Belt and KBO science from a purely astronomical pursuit, as it is today, to a geological and geophysical pursuit.”

“This is why we explore,” said Curt Niebur, New Horizons program scientist at NASA Headquarters in Washington. “The many discoveries from New Horizons represent the best of humankind and inspire us to continue the journey of exploration to the Solar System and beyond.”

The outer Solar System may be cold, remote, and seemingly desolate, but it is by no means boring.
